Backward Inclined Direct Drive Blower

SXBD Series

backward inclined direct drive blower

This blower design maximizes efficiency while reducing power loss, maintenance and troublesome adjustments.

The SXBDTM Series blower have a backward inclined wheel mounted directly on to the motor shaft. The motor is mounted outside the airflow and the design meets AMCA ‘C’ standards.

A range of motors/blowers are available to cover airflows up to 10 000 cfm at 12“ H2O.

Headlight Advantages

backward inclined direct drive blower

Reduced initial cost
With the absence of pulleys, fan bearings and belts, The high efficiency blower design offer competitive manufacturing costs and lower power consumption.

Low maintenance cost
The optional quick access door and the absence of pulleys, fan bearings and belts reduces maintenance time and costs.

Compact design
Mounts directly to the dust collector’s clean-air plenum, eliminating costly transitions.

Explosion-proof motor (optional)
This class of motor is rated for use in explosive areas (outside the dirty air stream).

Pressures available up to 15“ H2O
Static pressure capabilities help maintain CFM and air flow through heavy ductwork arrangement.

IMPROVE AIR HANDLING OF YOUR FACILITIES

I WANT TO KNOW MORE

Performance Curves

performance curves of direct drive blower

Model PCM H20 RPM Class Motor Weight (lbs) DBA at 5ft
CV Frame Ø Shaft
SXBD-01 1000 8.5 3450 IIs 5 184T 1.125 690 79.6
SXBD-02 2000 10.5 3450 IIs 7.5 213T 1.375 771 81.4
SXBD-04 4000 12 3450 III 15 254T 1.625 942 82
SXBD-05 5000 7 1750 III 15 254T 1.625 1032 78.9
SXBD-06 6000 12 3450 III 20 256TS 1.625 1168 85
SXBD-08 8000 12 1750 III 30 286T 1.875 1187 82
SXBD-10 10000 12 1750 III 30 286T 1.875 1193 82

Dimensions

direct drive blower dimensions

Blower
Model
General Dimensions Square Flange Dim. Circular Flange Dim.
A B C D E F G H I J K L M N Qty
SXBD-01 22 3/4” 25 7/8” 27 5/8” 12 1/2” 10 1/2” 7 7/8” 9 1/2” 14” 15” 10 1/4” 11 5/8” 13 1/2” 18” 16 1/2” 16
SXBD-02 25” 27 1/2” 32 3/8” 13 3/4” 11 1/2” 8” 10 1/8” 15” 16” 11 1/2” 12 7/8” 15” 18” 16 1/2” 16
SXBD-04 27 1/2” 31 1/4” 40 5/8” 14 3/4” 12 1/2” 9 3/4” 10 5/8” 16” 18” 12 3/4” 14 5/8” 16 1/2” 19 1/2” 18” 8
SXBD-05 39 1/4” 44 1/4” 46” 22” 17 1/2” 14 1/4” 13 3/8” 22” 25” 18 1/8” 21 5/8” 25” 28” 26 1/2” 16
SXBD-06 30” 34 3/8” 41 1/2” 17 3/4” 14” 10 3/8” 11 1/8” 17” 20” 13 5/8” 16 1/8” 18 1/2” 21 1/2” 20” 8
SXBD-08 47 3/4” 52 1/2” 47 7/8” 28” 21 1/2” 18” 14 1/4” 23” 30” 19 3/4” 26 1/8” 30 1/2” 33 1/2” 32” 16
SXBD-10 47 3/4” 54 1/2” 49 3/8” 28” 21 1/2” 18” 30 1/2” 25” 30” 21 3/8” 26 1/8” 30 1/2” 33 1/2” 32” 16
